MDT 300-46 Mill Duty Thruster Brake (For 300mm Drum)
A high-torque, fail-safe thruster brake for large 300mm drum systems in heavy-duty environments.
- High Braking Torque: Delivers a powerful 83 Kg-m of torque for maximum stopping power.
- Heavy-Duty Frame: Robust welded steel frame built for extreme industrial conditions.
- Powerful Thruster: Equipped with the reliable AT-546 (46 Kg) thruster.
- High-Frequency Operation: Engineered for up to 720 operations per hour.
Request a Quote for this Brake
Contact our team for the best pricing and to schedule a technical discussion.
Call for Enquiry Download Catalog Schedule Technical Discussion
Includes 1-Year Manufacturer Warranty
Technical Details & Video
| Model | MDT 300-46 |
| Brake Drum Diameter | 300 mm |
| Thruster Model Used | AT-546 (46 Kg) |
| Braking Torque | 83 Kg-m |
| Operations per Hour | Up to 720 |
| IP Rating | IP-55 |
Working Principle
The Thruster Brake is a fail-safe device. Braking force is applied to the brake shoes by a pre-stressed compression spring. When power is supplied to the integrated electro-hydraulic thruster, it overcomes the spring force and moves the brake shoes clear of the drum, allowing machinery to operate. When power is cut, the spring instantly applies the brake shoes to the drum, retarding speed and holding the load securely.
